General Purpose Corded Area Imager Bar Code Reader The Gryphon 4000 series represents the premium level of data collection devices from Datalogic Scanning for general purpose applications. Designed with people in mind, the Gryphon I GD4400 All-in-One imager blends advanced 2D decoding with motion sensing technology, producing a user-friendly device with outstanding performance.
Replacement Cables - RS232 INTERFACE CABLES
gryphon-i-gd4400-b-2d.pdf
| Scan Engine | Area Imager |
| Light Source | Aiming: 650 nm VLD |
| Scan Pattern | 752 x 480 Pixels |
| Scan Rate | |
| Motion Tolerance | 25 IPS |
| Image Capture | Graphic Formats: BMP, JPEG, TIFF GreyScale: 256, 16, 2, JPEG, TIFF |
| Capture Area | N/A |
| Contrast Ratio | 25% Minimum reflective difference |
| Resolution | Standard Range (SR): 1D Linear Max. 0.102mm / 4 mils Datamatrix 0.178mm / 7 mils PDF417 0.127mm / 5 mils High Density (HD): 1D Linear Max. 0.077mm / 3 mils Datamatrix 0.127mm / 5 mils PDF417 0.102mm / 4 mils |
| Depth of field | Standard Range (SR): Code 39: 5 mils - 4.0 to 19.0 cm Data Matrix: 10 mils - 2.0 to 16.0 cm Data Matrix: 15 mils - 0 to 23.6 cm EAN-13: 13 mils - 1.5 to 40.0 cm PDF417: 10 mils - 0.5 to 22.0 cm QR Code: 10 mils - 3.0 to 12.5 cm High Density (HD) Code 39: 3 mils - 2.4 to 9.1 cm Code 39: 5 mils - 0.8 to 11.3 cm Data Matrix: 5 mils - 2.8 to 6.1 cm EAN-13: 13 mils - 1.1 to 17.2 cm PDF417: 4 mils - 1.8 to 6.8 cm PDF417: 10 mils - 0 to 14.3 cm QR Code: 6.7 mils - 2.1 to 4.2 cm Performance may be impacted by Bar code quality and environmental conditions |
| Tilt Angle | 180° |
| Pitch Angle | +/- 40° |
| Skew Angle | +/- 40° |
| Ambient Light Immunity | 0 - 100,000 Lux |
| Symbologies supported | 1D:Auto-discriminates all standard 1D codes including GS1 DataBar™ linear codes 2D:Aztec Code; China Han Xin Code; Data Matrix; MaxiCode; Micro QR Code; QR Code Postal Codes: Australian Post; China Post; IMB; Japanese Post; KIX Post; Planet Code; Portuguese Post; Postnet; Royal Mail Code (RM4SCC); Swedish Post Stacked Codes: EAN/JAN Composites; GS1 DataBar Composites; GS1 DataBar Expanded Stacked; GS1 DataBar Stacked; GS1 DataBar Stacked Omnidirectional; MacroPDF; MicroPDF417; PDF417; UPC A/E Composites |
| Programming Method | Manual: Reads special bar codes Automatic: Software commands through the RS-232 / USB interfaces Datalogic Aladdin™: Windows configuration program Remote Host Download (Lowers service costs and improves operations) |
| Driver available | JavaPOS, OPOS Utilities |
| Indicators/Controls | Scanner Indicators: Good Read LED "Green spot" on the code Adjustable tone beeper |
| Communication Type | Corded |
| Interfaces | GD4430: USB, RS232, Wedge & Wand Multi Interface GD4410: RS232, IBM 46XX, USB Multi Interface |
| Supply Voltage | GD4430 4.2-5.25 VDC GD4410 4.0-14.0 VDC |
| Power Consumption | GD4430: Operating typical <160mA @ 5V GD4410: Operating typical <170mA @ 5V Standby/Idle Typical 65 mA @ 5V |
| Drop Specification | Withstands repeated drops from 1.8 m onto a concrete surface |
| Environmental Sealing | IP52 |
| ESD Protection | +/- 16 kV air discharge |
| Operating Environment | 0° ~ 50°C, Relative Humidity 5 - 95% none condensing |
| Storage Environment | -20° ~ 70°C, Relative Humidity 5 - 95% none condensing |
| EMC/Safety Standards | Caution Laser Radiation - Do not stare into beam; IEC 60825 Class 2 |
| External Dimensions (WxDxH) | Scanner: 71 x 100 x 181mm |
| Weight | 195g |
| Warranty | 5 Year Factory Warranty (not on cable, conditions apply) |
